Lightweight Portables
| EX350 | EM650 | EG650 | EX650 | EX1000 | |
| Features | |||||
| Honda 4-stroke side valve engine |  |
 |
|
|
|
| Oil Alert | |
|
|
||
| Electronic Ignition | |
|
|
|
|
| Can be carried with one hand | |
|
|
|
|
| Simultaneous AC/DC use | |
|
|
|
|
| AC/DC circuit breakers | |
|
|
|
|
| Fuel Meter | |
|
|||
| Frequency Meter | |
|
|
||
| One switch for engine/fuel valve on/off | |
|
|
|
|
| Large fuel tank capacity | |
|
|||
| USDA-qualified spark arrestor/muffler | |
|
|
|
|
| Fully enclosed for quieter operation | |
|
|
|
|
| Specifications | EX350 | EM650 | EG650 | EX650 | EX1000 |
| Engine | |
1.6HP Side Valve | 2.2HP Side Valve | 1.6HP Side Valve | 2HP Side Valve |
| Displacement | 34cc | 76cc | 83cc | 76cc | 97cc |
| AC output | 120V 350W max (2.9A) 150W max (1.25A) 300W rated (2.5A) |
120V 650W max (5.4A) 550W rated (4.6A) |
120V 650W max (5.4A) 550W rated (4.6A) |
120V 650W max (5.4A) 550W rated (4.6A) |
120V 1000W max (8.3A) 900W rated (7.5A) |
| Receptacles | A | B | A(2) | A(2) | A(2) |
| DC output | 12V, 72W (6.0A) |
12V, 100W (8.3A) |
12V, 100W (8.3A) |
12V, 100W (8.3A) |
12V, 100W (8.3A) |
| Starting system | Recoil | Recoil | Recoil | Recoil | Recoil |
| Fuel tank capacity | 0.2 gallons | 0.7 gallons | 0.3 gallons | 0.5 gallons | 0.8 gallons |
| Operational capacity on one tankfull** |
Approx. 1.8 hrs/3 hrs | Approx. 5.3 hrs | Approx. 2.5 hrs | Approx. 3.8 hrs | Approx. 3.8 hrs |
| Dimensions (L x W x H) | 14.4" x 6.9" x 11.8" |
16.1" x 10.6" x 14.8" |
13.8" x 11.8" x 14.2" |
17.0" x 10.6" x 14.8" |
16.9" x 11.4" x 15.4" |
| Noise level | 58/50 dB | 56 dB | 67 dB | 54 dB | 64 dB |
| Dry weight | 19 lbs. | 48 lbs. | 42 lbs. | 51 lbs. | 57 lbs. |
| EX350 | EM650 | EG650 | EX650 | EX1000 |
| RECEPTACLE | RATING | NEMA PLUG NUMBER |
| A | 15A 125V SINGLE | 5-15P |
| B | 15A 125V DUPLEX | 5-15P |
EX350 uses .9HP two-stroke engine.
**Estimate only, based on rated load.
